MALAYSIA | Railways

This project involves the construction of a new track (179 km) and upgrading of the existing track to allow for a maximum design speed of 160 kph. The other components of the project involved the construction of new concrete railway bridges, culverts, 14 stations, 40 overhead road bridges to eliminate all level crossings, construction of a new EMU Depot at Batu Gajah, overhead 25kV 50Hz electrification system, modern signalling and communication, Automatic Fare Collection system, land acquisitions and relocation of squatters

Route Map: Rawang - Ipoh EDT Project





The main objectives are:-
- to extend the existing KTM Komuter service from Seremban - Rawang to Tg. Malim with an average number of 100 services per day.
- introduction of a rapid intercity service, between Ipoh and Sentral KL Sentral, with 16 services per day in the beginning and ultimately 32 services per day.
- to upgrade existing rail infrastructure for the increase in track capacity for Komuter, Intercity and freight trains.


The Contract for Infrastructure Package was awarded to DRB-HICOM on 17 July 2000 and System Package awarded to Mitsui Co. Ltd. - Mitsui Transportation Systems Consortium on 10 January 2001.


The work under the infrastructure package has been 18 months behind schedule. This has resulted in consequential delays to the system works. However, recovery programme have been instituted by both contractors to mitigate the delay and the progress is being monitored closely by the special committee led by the Ministry of Transport to ensure successful completion of the project.

With the commissioning of the project which is expected by early 2007, KTM Berhad will be able to introduce rapid intercity trains from Kuala Lumpur to Ipoh and extend the KTM Komuter services from Rawang to Tanjung Malim
